Road Construction Fiberglass Geogrid Reinforcing Fabric For Base Reinforcement

Product Details

Place of Origin: CHINA

Brand Name: FC

Certification: CE/ISO9001

Model Number: FC13009

Payment & Shipping Terms

Minimum Order Quantity: 1000SQUARE METER

Price: NEGOTIATED

Packaging Details: 1,50kn-50kn:3.95m(W)*l100m(L) per roll,about 53000m2/40HQ 2,100kn-100kn:3.95m(W)*l100m(L) per roll,about 41000m2/40HQ

Delivery Time: 15-20DAYS

Payment Terms: D/A, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability: 30000 Square Meter/Square Meters per Day

Get Best Price
Contact Now
Specifications
Highlight:

geotextile road fabric

,

asphalt reinforcement fabri

MATERIAL:
PLASTIC
Strength:
25-300KN/m
WIDTH:
2.5M
LEAD TIME:
15DAYS
MESH SIZE:
25*25 40*40 50*50
LOAD PORT:
SHANGHAI OR NINGBO
MATERIAL:
PLASTIC
Strength:
25-300KN/m
WIDTH:
2.5M
LEAD TIME:
15DAYS
MESH SIZE:
25*25 40*40 50*50
LOAD PORT:
SHANGHAI OR NINGBO
Description
Road Construction Fiberglass Geogrid Reinforcing Fabric For Base Reinforcement

road construction geogrid fiberglass geogrid reinforcing fabric for Base reinforcement



1) Plastic geogrid
2) Materials:plastic
3) Tensile strength:MD/CD:30~300kn/m
4) Width:2.5m



Uniaxial Polypropylene Geogrids


1  The Uniaxial Polypropylene Geogrids is made of PP and PE Materials.

2 ,Adding Anti-ultraviolet and Anti-aging agent.

3, High strength orientatipn stretch and shape of ollipse.

Application in Dam, Tunnel ,Wharf, Highway, Railway, Building



SPECIFICATION FOR UNIAXIAL POLYPROPYLENE GEOGRID

Model
Tensile Strength

≥KN/M
Tensile Strength
2% Elongation
≥KN/M
Tensile Strength
5% Elongation
≥KN/M
Elongation

%≤
Carbon
content
%≤
Width

M
TGDG50
50
12
28












10%












2.0












2.5
TGDG60
60
15.5
33
TGDG80
80
26
48
TGDG100
100
31
60
TGDG110
110
33.5
66
TGDG120
120
36
72
TGDG130
130
38.5
76.5
TGDG150
150
43
85.5
TGDG160
160
45
90
TGDG180
180
50.5
101
TGDG200
200
56
112
TGDG220
220
62.5
125
TGDG260
260
74
147
TGDG280
280
80
158
TGDG300
300
85.5
169.5
Product Application

The Application of Uniaxial Geogrids


Reinforcement Zoology side slope for Geogrids

Reinforcement Zoology side slope for Backpacks formed

Reinforcement Zoology side slope for Hillslope Greening form

Reinforcement steep side slope for Geogrids

Foundation reinforce for Strength Uniaxial Geogrids

Reinforcement barricade for Geogrids







Product Description



Reinforcements geogrid basalt fiber geogrid/fiber glass geogrid

Basalt fiber geotextile (geogrid) is a kind of semi-rigid products, which uses high-strength basalt fibers to produce gridding base material with advanced knitting process, and then treated by surface coatings. Both warp and weft directions are high tensile strength and low elongation. Breaking elongation is 3.1%. The properties are high-temperature resistance, cold resistance (-260℃-650℃), acid etching resistance , little creep, high strength, and little deformation. It is acid-resistant and alkali-resistant, low-temperature and high-temperature resistant, thermal and sound insulation. Its tensile strength is better than that of lager tows carbon fiber, and the breaking elongation is even better than small bunch carbon fiber. It has better compression strength, shearing strength, and applicability & aging resistance in severe environment, etc.





Feature



1. Can be used under super-low temperature and have good thermal stability
2. High tensile strength and low elongation
3. Good physical and chemical stability, strong resistance to biological erosion and climate changes.





Advantage



1. Super high temperature and ultra low temperature performance, prevent the asphalt pavement cracks
2. High tensile strength
3. No long term creep, and good thermal stability
4. Good compatibility with asphalt mixture
5. Stable physical and chemical properties, good resistance against biological erosion and climate change





Application



1,  Subgrade strengthening and pavement repairing for highways, railways and airports.
2,  Subgrade strengthening of perpetual load bearing,such as large parking lots and cargo terminals.
3,  Slope protections of highways and railways
4,  Culvert reinforcing
5.  Mines and tunnels reinforcing.



Road Construction Fiberglass Geogrid Reinforcing Fabric For Base Reinforcement 0
